MBI6353 is an advanced 48-channel high power constant current full-array local dimming (FALD) backlighting LED driver for large-mid LCD panel applications. The innovative architecture is designed to support up to 1:4 time-multiplexing and control up to 192 LED dimming zones application using internal Pulse Width Modulation Dimming(P-DIM) and Analog Dimming(A-DIM) control with 12-bit color depth and extra 2-bits high luminance mode by zone to improve contrast ratio for HDR applications.
Both compulsory and real-time LED error open/short detection and protection are included during both start-up and normal operation. Besides, MBI6353 also provides DC/DC feedback control, ghost elimination function and over temperature protection features.
MBI6353 产品规格
-
ItemsSpec.Content
-
01输出通道数48
-
02每通道输出电流值4~100mA
-
03输出管脚耐压24V
-
04输出电流精确度-通道间<±3.0％ (max.)
-
05输出电流精确度-IC间<±3.0％ (max.)
-
06内建 MOSFET
-
07传输界面SPI 、菊链
-
08传输方法Burst 模式
-
09扫描设计最高4扫
-
10错误侦测-LED开路
-
11错误侦测-LED短路
-
12电流增益8-bit
-
13调光方式12-bit PWM
10-bit PAM -
14动态同步
-
15回授控制
-
16保护功能-过热
-
17RoHS环保封装QFN-68 8X8
-
18主要应用屏幕、TV
