MBI6312

2-channel High Power Constant Current Full Array Local Dimming (FALD) Backlight LED Driver

MBI6312 is an advanced 12-channel high power constant current full array local dimming (FALD) backlight LED driver for mid-sized LCD panel applications. This innovative architecture is designed to support BCON-less static LED dimming applications. It uses internal pulse-width modulation dimming (P-DIM) with 12-bit color depth and analog dimming (A-DIM) with 10-bit color depth to achieve better PQ. Another new technology is the special data transmission design, which can achieve the lowest latency display effects.

Includes real-time LED false open/short detection and protection during startup and normal operation. In addition, MBI6312 also provides DC/DC feedback control, ghost elimination function, and over-temperature protection function.

MBI6312 产品规格

  • Items
    Spec.
    Content
  • 01
    输出通道数
    12
  • 02
    每通道输出电流值
    4~81mA
  • 03
    输出管脚耐压
    45V
  • 04
    输出电流精确度-通道间
    <±3.0% (max.)
  • 05
    输出电流精确度-IC间
    <±3.0% (max.)
  • 06
    内建 MOSFET
  • 07
    传输界面
    SPI-like W/Bcon less
  • 08
    传输方法
    无Burst模式
  • 09
    扫描设计
  • 10
    错误侦测-LED开路
  • 11
    错误侦测-LED短路
  • 12
    电流增益
    6-bit
  • 13
    调光方式
    12-bit PWM
    10-bit PAM
  • 14
    回授控制
  • 15
    保护功能-过热
  • 16
    RoHS环保封装
    QFN-24 4x4
  • 17
    主要应用
    TV
